Description

Three phase 20-75 Amps

The Sollatek SVS monitors the mains voltage continuously. If the voltage rises or drops, the SVS will stabilise the output to ensure the voltage reaching your equipment remains constant at 230V (+/-6%), within the operating range of the unit. If the input voltage falls below 142V or rises above 295V, the SVS will disconnect the output, thereby protecting the load. Once the mains voltage returns again within acceptable limits, the SVS will reconnect the output following a start up delay.

Specification

Model	Amps	kVA@ 230V/400	Weight (KG)	Dims (mm)
SVS3x20-22	3×20	13.8	50	400x400x645
SVS3x35-22	3×35	24.2	65	400x400x645
SVS3x50-22	3×50	34.5	85	400x400x645
SVS3x75-22	3×75	51.7	110	550x600x750

Downloads
Brochures
- Voltright SVS Brochure – English (2MB)
Datasheets
- SVS3x45 Datasheet (1MB)
Instruction Manuals
- SVS 3Phase User Manual (2MB)
